2 Hp Single Phase Induction Motor

Name: 2 Hp Single Phase Induction Motor
Brand: TARANG ENGINEERING
Price: 8500 INR
Availability: InStock

Price 8500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

2 Hp Single Phase Induction Motor Specification

Voltage
230 V

Noise Level
<65 dB

Rated Voltage
230 V

Current Type
AC

Rated Frequency
50 Hz

Torque
13.27 Nm

Pressure
Atmospheric

Power Rating
2 Hp

Horse Power
2 Hp

Motor Type
Induction Motor

Cooling Method
Air Cooling

Poles Number
4

Starting Type
Capacitor Start

Bearing Type
Ball Bearing

Efficacy
IE2

Sealed Type
Sealed bearing

Ambient Temperature
-20C to +50C

Product Type
Single Phase Induction Motor

Output Power
2 Hp

Frequency (MHz)
0.05 MHz

Protect Feature
Totally Enclosed Fan Cooled (TEFC)

Phase
Single Phase

Speed
1440 rpm

Power
1.5 kW

Color
Blue

Dimension (L*W*H)
420 mm x 235 mm x 260 mm

Weight
32 kg

Shaft Diameter
28 mm

Mounting Type
Foot Mounted

IP Rating
IP55

Base Type
Ribbed Base

Paint Type
Industrial Blue

Duty Type
S1 Continuous

Frame Size
112M

Material
Cast Iron

Terminal Box Position
Top

Winding Type
Copper Winding

Insulation Class
Class B

Service Factor
1.15

Fan Type
External Fan

2 Hp Single Phase Induction Motor Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About 2 Hp Single Phase Induction Motor

Experience the sublime performance of the 2 Hp Single Phase Induction Motor, a trending and in-demand solution crafted for a range of industrial and commercial applications. With its ephemerally smooth operation and dominant output power of 2 Hp (1.5 kW), this enlightened design features copper winding, a robust cast iron body, and a ribbed base for increased durability. The industrial blue finish and top terminal box position reflect purposeful aesthetics suited for modern sites. Enjoy elevated reliability, TEFC protection, and high efficiency (IE2), making it a sought-after choice for both established and emerging markets.

Sublime Features and Versatile Usage

This 2 Hp Single Phase Induction Motor boasts advanced features such as copper winding, Class B insulation, and a totally enclosed fan cooled design for robust performance. Ideal for diverse application surfaces, it excels in pumps, compressors, and conveyor systems, making it suitable for industries, workshops, and even agricultural operations. Its sturdy cast iron construction and external fan ensure longevity, while the ribbed base provides stable mounting on any standard industrial platform.

Dominant Reach and Quick Dispatch Markets

Our 2 Hp Single Phase Induction Motor is not only popular in the vast Indian domestic market but is also exported to regions across Asia, Africa, and the Middle East. With a competitive sale price and excellent outlay value, supply ability is consistently maintained with quick dispatch times. Bulk orders and timely delivery ensure seamless availability for project deployments, enhancing business productivity without delays.

FAQ's of 2 Hp Single Phase Induction Motor:

Q: How is the 2 Hp Single Phase Induction Motor beneficial for continuous operations?

A: The motor, designed with S1 continuous duty type and TEFC protection, offers consistent and uninterrupted performance, making it highly reliable for 24/7 industrial and agricultural applications.

Q: What makes the copper winding in this motor an enlightened choice?

A: Copper winding ensures lower electrical losses, better thermal conductivity, and higher efficiency compared to other materials, resulting in improved performance and longevity.

Q: Where can the 2 Hp Single Phase Induction Motor be installed?

A: It is versatile for both indoor and outdoor installations on foot-mounted platforms, suitable for pumps, compressors, conveyors, and allied machinery in factories, farms, and processing units.

Q: When is the product typically dispatched after order placement?

A: Thanks to our streamlined supply chain, quick dispatch is ensured, with products usually shipped within a few business days depending on order volume and destination.

Q: What surfaces and applications are best suited for this induction motor?

A: The motor performs optimally on stable industrial bases including factory floors, workshops, and agricultural sites, supporting applications like fluid pumping, material conveyors, and fan operations.

Q: How does the Totally Enclosed Fan Cooled (TEFC) feature enhance motor usage?

A: The TEFC design prevents contaminants from entering the motor, ensuring superior cooling and extending operational life even in dusty or moist environments.
